Axiomatic Releases a CAN-Ethernet Support Package

Axiomatic releases a CAN-Ethernet Support Package (SSP) for developing application software when working with the AX140900 CAN/Ethernet Converter.
The SSP is a set of software modules and examples for users of the AX140900 Ethernet-CAN Converter. It is written is a standard C programming language. The modules provide support for the Axiomatic Proprietary Communication and Discovery Protocols. The Communication Protocol is for transmitting CAN messages over the Ethernet TCP/IP network and the Discovery Protocol is for locating the converter on the LAN. The SSP is useful for programming embedded systems and for application programming in Windows or Linux.

The CAN/Ethernet Converter, P/N: AX140900, converts CAN frames into UDP or TCP IP datagrams and sending them over the Ethernet network. The device can also convert UDP or TCP datagrams into CAN frames. It supports a high-speed CAN with a baud rate of up to 1Mbit/s and a fast 100Mbit/s Ethernet. All standard and extended CAN frames, including data and remote frames, are supported. The power can be passed through to the CAN port. Protection is provided. To ensure low latency in processing CAN and Ethernet messages, the converter software runs under control of a real-time operating system.

The converter is designed to work on off-road machinery or in a harsh industrial environment with power transients, high humidity and vibrations. It can be used out-of-the box without the SSP for interfacing between Ethernet devices and the machine CAN network. One or more converters can be installed depending on the number of CAN busses in the system.

The converter contains a web server to setup configuration parameters and monitor the internal state of the converter using a web browser. The user can remotely monitor and configure Axiomatic CAN-based controllers over the internet using the AX140900 CAN/Ethernet Converter together with the Axiomatic EA and CAN-Scope software. We call this service tool EA-Connect.

Other Axiomatic connectivity products include the Ethernet Switch as well as the CANBluetooth and CAN-Wifi converters.
Axiomatic’s product will be showcased as part of a system integration in the Bailey International LLC booth at IFPE, which will be held in conjunction with CONEXPO-CON/AGG, March 7-11, 2017, in Las Vegas, Nevada.

Source: Axiomatic Technologies Corporation
